Couplers

Scraped SKU: skf-couplers 2026-06-13 07:52:24

Attributes

Alemite Seriesgrease-guns

Description

Alemite Couplers provide quick, positive and leakproof connection with fittings.

Variations (23)

6304-B

Thread1/8" NPTF(f)
TypeStandard
Length-
Pressure10,000 psi (690 bar)
Other FeaturesMetal Seal
GroupHydraulic Couplers

6304-C

Thread1/8" NPTF(f)
TypeStandard
Length-
Pressure10,000 psi (690 bar)
Other FeaturesMetal Seal; built-in check valve
GroupHydraulic Couplers

308730

Thread1/8" NPTF(f)
TypeNarrow
Length-
Pressure10,000 psi (690 bar)
Other FeaturesRubber Seal
GroupHydraulic Couplers

308730-A

Thread1/8" NPTF(f)
TypeNarrow
Length-
Pressure10,000 psi (690 bar)
Other FeaturesRubber Seal; built-in check valve
GroupHydraulic Couplers

B330070

Thread1/8" NPTF(f)
TypeNarrow
Length-
Pressure10,000 psi (690 bar)
Other FeaturesMetal Seal; blister packed
GroupHydraulic Couplers

B154

Thread1/8" NPTF(f)
TypeNarrow
Length-
Pressure10,000 psi (690 bar)
Other FeaturesRubber Seal & 4 Jaw design
GroupHydraulic Couplers

322120

Thread1/8" NPTF(f)
TypeNarrow
Length-
Pressure10,000 psi (690 bar)
Other FeaturesRubber Seal; 90°
GroupHydraulic Couplers

6509-D

Thread1/8" NPTF(f)
TypeSandard 360° Swivel
Length3-1/2"
Pressure10,000 psi (690 bar)
Other FeaturesMetal Seal
GroupHydraulic Couplers

6509-E

Thread1/8" NPTF(f)
TypeNarrow 360° Swivel
Length4"
Pressure10,000 psi (690 bar)
Other FeaturesRubber Seal
GroupHydraulic Couplers

42030

Thread7/16"-27 NS-2(f)
TypeStandard Pull-On
Pressure10,000 psi (690 bar)
Other Features-
GroupButton Head Couplers

42030-A

Thread1/8" NPTF(f)
TypeStandard Pull-On
Pressure10,000 psi (690 bar)
Other Features7/16 - 27 x 1/8” NPT(f) Threaded adapter ( 305859 ) Gasket ( 50679 )
GroupButton Head Couplers

42031-A

Thread1/8" NPTF(f)
TypeStandard Push-On
Pressure10,000 psi (690 bar)
Other Features7/16 - 27(m) x 1/8” NPT(f) Threaded adapter ( 305859 ) Gasket ( 50679 )
GroupButton Head Couplers

304300

Thread7/16"-27 NS-2(f)
TypeGiant Pull-On
Pressure15,000 psi (1,030 bar)
Other Features-
GroupButton Head Couplers

304300-A

Thread1/8" NPTF(f)
TypeGiant Pull-On
Pressure15,000 psi (1,030 bar)
Other Features7/16 - 27 x 1/8” NPT(f) Threaded adapter ( 305859 )
GroupButton Head Couplers

319702

Thread1/4" PTF SAE Short(f)
TypeGiant Pull-On
Pressure15,000 psi (1,030 bar)
Other Features-
GroupButton Head Couplers

304301

Thread7/16"-27 NS-2(f)
TypeGiant Push-On
Pressure15,000 psi (1,030 bar)
Other Features-
GroupButton Head Couplers

398727

DescriptionStandard Button Head Coupler Kit
GroupCoupler Kits

398726

DescriptionGiant Button Head Coupler Kit
GroupCoupler Kits

VB942

Thread1/8" NPTF(f) without wing
TypePin
Pressure5,000 psi (345bar)
GroupPin Type Couplers

50491

Thread1/8" NPTF(m) with wing
TypePin
Pressure5,000 psi (345 bar)
GroupPin Type Couplers

51185

Thread1/8" NPTF(f) with wing
TypePin
Pressure5,000 psi (345 bar)
GroupPin Type Couplers

314150

Thread1/8" NPTF(f)
TypeMidget
Pressure10,000 psi (690 bar)
GroupFlush Type Nozzle Couplers

Z737

Thread1/8" NPTF(f)
TypeStandard
Pressure10,000 psi (690 bar)
GroupFlush Type Nozzle Couplers

Specifications

TypesHydraulic Couplers; Button Head Couplers; Pin Type Couplers

PDF Documents

No PDF documents.
