Attributes
| Alemite Series | reels |
|---|
Description
Alemite Heavy Duty Reels set the industry standard for reliable, rugged performance in tough work environments. Engineered for optimum performance and safety, these reels are suitable for a wide range of demanding applications.
Variations (9)
8078-C
| Color | Maroon |
|---|---|
| Max Pressure | 1,500 psi (103 bar) |
| Delivery Hose | 1/2" ID x 30 ft |
| Connecting Hose | 1/2" NPTF(m) |
| Weight | 58 lb (26 kg) |
8078-D
| Color | Maroon |
|---|---|
| Max Pressure | 1,500 psi (103 bar) |
| Delivery Hose | 1/2" ID x 50 ft |
| Connecting Hose | 1/2" NPTF(m) |
| Weight | 58 lb (26 kg) |
8078-DBL
| Color | Blue |
|---|---|
| Max Pressure | 1,500 psi (103 bar) |
| Delivery Hose | 1/2" ID x 50 ft |
| Connecting Hose | 1/2" NPTF(m) |
| Weight | 58 lb (26 kg) |
8078-DBK
| Color | Black |
|---|---|
| Max Pressure | 1,500 psi (103 bar) |
| Delivery Hose | 1/2" ID x 50 ft |
| Connecting Hose | 1/2" NPTF(m) |
| Weight | 58 lb (26 kg) |
8078-DW
| Color | White |
|---|---|
| Max Pressure | 1,500 psi (103 bar) |
| Delivery Hose | 1/2" ID x 50 ft |
| Connecting Hose | 1/2" NPTF(m) |
| Weight | 58 lb (26 kg) |
7135-A
| Color | Blue |
|---|---|
| Usage | Oil |
| Max. Pressure | 1,500 psi (103 bar) |
| Inlet | 1/2" NPTF(f) |
| Outlet | 1/2" NPTF(f) Swivel |
| Weight | 50 lb (23 kg) |
| Group | Bare reels |
7335-B
| Color | Black |
|---|---|
| Usage | Oil |
| Max. Pressure | 1,500 psi (103 bar) |
| Inlet | 1/2" NPTF(f) |
| Outlet | 1/2" NPTF(f) Swivel |
| Weight | 50 lb (23 kg) |
| Group | Bare reels |
7135-C
| Color | White |
|---|---|
| Usage | Oil |
| Max. Pressure | 1,500 psi (103 bar) |
| Inlet | 1/2" NPTF(f) |
| Outlet | 1/2" NPTF(f) Swivel |
| Weight | 50 lb (23 kg) |
| Group | Bare reels |
7135-D
| Color | Maroon |
|---|---|
| Usage | Oil |
| Max. Pressure | 1,500 psi (103 bar) |
| Inlet | 1/2" NPTF(f) |
| Outlet | 1/2" NPTF(f) Swivel |
| Weight | 50 lb (23 kg) |
| Group | Bare reels |
Specifications
| Included items | Hose Reel; Hose; Hose Stop; Union; 24" (61 cm) Connecting Hose |
|---|---|
| Features | Superior Performance – Swivel and reel ball bearings reduce torque load on power spring for smooth retraction every time; Anti-Lockout Design – Ratchet prevents lockup when hose is fully extended, eliminating the need to manually release the pawl at the reel; Corrosion Resistant – Sealed bearings prevent contamination and minimize maintenance, a critical performance factor in dirty environments; Easy Installation and Maintenance – Factory lubricated one piece power spring cassette makes installation and maintenance safe and easy; Durable – Heavy metal arbor design withstands extreme stress and eliminates breakage associated with non-metal and light weight metal arbors; Adjustable and Versatile – 5 position guide arm allows hose to release at an optimum position. Narrow design allows for efficient use of available space |
| Compatibility | Oil; Grease; Air; Water |
