Attributes
| Alemite Series | fittings |
|---|
Description
Alemite Vents are used with transmissions, speed reducers, axles, gear housings and similar applications. The vent is placed above normal lubrication level to allow air to escape when internal pressure rises.
Variations (7)
300805
| Thread | 1/8" PTF SAE Short |
|---|---|
| Opening Pressure | Felt filter |
304810
| Thread | 1/8" PTF SAE Short |
|---|---|
| Opening Pressure | 1-3" water |
324970
| Thread | Drive 3/8". Designed as 0.374 ±0.000-0.003 drive. Use 0.368" drill or U drill. |
|---|---|
| Opening Pressure | 6-12" water 0.25 to 0.43 psi |
131000-T
| Thread | 1/8" PTF SAE Short |
|---|---|
| Opening Pressure | 12" water max |
327240
| Thread | 1/8" PTF SAE Short |
|---|---|
| Opening Pressure | 1 to 1-1/2 psi |
330766
| Thread | 1/8" PTF SAE Short |
|---|---|
| Opening Pressure | 2-1/2 to 4 psi |
369622
| Thread | 1/8" PTF SAE Special Short |
|---|---|
| Opening Pressure | 2-1/2 to 4 psi |
Specifications
| Features | Exceeds 72 hour salt spray test; Trivalent zinc plating; Vent opens at designated pressure; Helps to prevent fluid leakage; Special cap prevents water or dirt from entering |
|---|
PDF Documents
No PDF documents.
